- Fast curing for minimum disruption
- Easy to apply
- Self-priming and tolerant to application on cold, damp surfaces
- Easy to clean and sterilise anti-slip surface, minimal joints
- Wide range of colour and size aggregates available
- Low maintenance can be further enhance with Page Rapid Set Seal Coat
- Life expectancy of 10 years in most environments
- Fit for traffic after approx 2 hours
- Easily passes TRL scuffing test for type 1 surfacing
- Erosion index zero (0 best, 30 worst, pass mark)
- Can achieve high slip resistance
- Texture index 1.4 (pass mark>=1.2)
Pageset Resin Bonded Surfacing is a fast curing resin bonded aggregate surfacing system for providing hardwearing slip resistant decorative floor ing for foot, vehicle and heavier traffic. It creates the look of natural aggregate without the mess of loose gravel.
FeRFA Resin Flooring guidelines
Floor seal
Description:
Applied in two or more coats. Generally solvent or water borne.
Duty:
light foot traffic, occasional rubber tyred vehicles.
Typical Thickness:
up to 150 µm
Floor coating
Description:
Applied in two or more coats. Generally solvent free.
Duty:
light foot traffic, occasional rubber tyred vehicles/regular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys
Typical Thickness:
150 µm to 300 µm
High build floor coating
Description:
Applied in two or more coats. Generally solvent or water borne.
Duty:
lregular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys
Typical Thickness:
300 µm to 1000 µm
Multi-layer flooring
Description:
Aggregate dressed systems based on multiple layers of floor coatings or flow-applied floorings, often described as ‘sandwich’ systems.
MD/HD
Duty:
regular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys/constant fork lift truck traffic, hard plastic wheeled trolleys, some impact
Typical Thickness:
> 2 mm
Flow applied flooring
Description:
Often referred to as ‘self-smoothing’ or ‘self-levelling’ flooring and having a smooth surface.
Duty:
regular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys/constant fork lift truck traffic, hard plastic wheeled trolleys, some impact
Typical Thickness:
2 mm to 3 mm
Resin screed flooring
Description:
Trowel-finished, heavily filled systems, generally incorporating a surface seal coat to minimize porosity.
Duty:
regular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys/constant fork lift truck traffic, hard plastic wheeled trolleys, some impact
Typical Thickness:
> 4 mm
Heavy duty flowable flooring
Description:
Having a smooth surface.
Duty:
constant fork lift truck traffic, hard plastic wheeled trolleys, some impact/severe heavily loaded traffic and impact
Typical Thickness:
4 mm to 6 mm
Heavy duty resin flooring
Description:
Trowel-finished, aggregate filled systems effectively impervious throughout their thickness.
Duty:
severe heavily loaded traffic and impact
Typical Thickness:
> 6 mm
Pageset Resin Bonded Surfacing can be applied to most substrates and dependant on the type of aggregates cast onto the surface provides superb hardwearing grip and traction for both foot and vehicle traffic, maximising slip resistance and enhancing the appearance.
It is suitable for public areas, industrial, commercial, retail and domestic use such as landscaping, factories, car parks, ramps, museums, steps, platforms, footbridges, driveways, patios, roads, cycle paths, indoor markets, roof gardens and general public areas.
It assists in meeting requirements of Disability Discrimination Act 1995.
It must be laid onto a sound stable and solid base such as concrete or tarmac and can be applied to bituminous, cementitious, metal and timber surfaces. Suitable for internal & external application.
