Warehouse floor chemical resist

A solvent and water free, epoxy resin, liquid applied surface damp proof membrane, designed to withstand moisture vapour from substrates.

Download PDF Brochure

With Pageseal DPM, Isocrete 1500 high strength (30 N/mm2) levelling screed and Page resin finish, the entire floor construction is available from one supplier.

  • Reduces project timescale, allows early installation of floor finishes
  • Impervious to water
  • Excellent adhesion to concretes and screeds
  • Tolerates up to 100% Relative Humidity in the concrete or screed substrate
  • Easy to apply
  • Solvent free, low odour
  • Excellent gap filling properties
  • Contrasting colour coats allows for visual control of the Pageseal DPM membrane uniformity in laying
  • The Pageseal DPM System can be used for either heavy duty industrial or medium to light duty commercial applications
  • Contrasting colour coats allows for visual control of the Pageseal DPM membrane uniformity in laying
FeRFA Resin Flooring guidelines

Floor seal

Description:

Applied in two or more coats. Generally solvent or water borne.

Duty:

light foot traffic, occasional rubber tyred vehicles.

Typical Thickness:

up to 150 µm

Floor coating

Description:

Applied in two or more coats. Generally solvent free.

Duty:

light foot traffic, occasional rubber tyred vehicles/regular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys

Typical Thickness:

150 µm to 300 µm

High build floor coating

Description:

Applied in two or more coats. Generally solvent or water borne.

Duty:

lregular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys

Typical Thickness:

300 µm to 1000 µm

Multi-layer flooring

Description:

Aggregate dressed systems based on multiple layers of floor coatings or flow-applied floorings, often described as ‘sandwich’ systems.
MD/HD

Duty:

regular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys/constant fork lift truck traffic, hard plastic wheeled trolleys, some impact

Typical Thickness:

> 2 mm

Flow applied flooring

Description:

Often referred to as ‘self-smoothing’ or ‘self-levelling’ flooring and having a smooth surface.

Duty:

regular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys/constant fork lift truck traffic, hard plastic wheeled trolleys, some impact

Typical Thickness:

2 mm to 3 mm

Resin screed flooring

Description:

Trowel-finished, heavily filled systems, generally incorporating a surface seal coat to minimize porosity.

Duty:

regular foot traffic, frequent fork lift truck traffic, occasional hard plastic-wheeled trolleys/constant fork lift truck traffic, hard plastic wheeled trolleys, some impact

Typical Thickness:

> 4 mm

Heavy duty flowable flooring

Description:

Having a smooth surface.

Duty:

constant fork lift truck traffic, hard plastic wheeled trolleys, some impact/severe heavily loaded traffic and impact

Typical Thickness:

4 mm to 6 mm

Heavy duty resin flooring

Description:

Trowel-finished, aggregate filled systems effectively impervious throughout their thickness.

Duty:

severe heavily loaded traffic and impact

Typical Thickness:

> 6 mm

Pageseal DPM: Allows immediate installation of moisture sensitive floor finishes onto concrete and cementitious screeds which have a moisture content of up to 100% Relative Humidity.

Pageseal One Coat: Allows immediate installation of moisture sensitive floor finishes onto concrete and cementitious screeds which have a moisture content of up to 85% Relative Humidity.

Project References: Bank of England, PC World, Boots, Rolls-Royce, Marks & Spencer, Curry’s, Dixons, BAE Systems; White Crescent Press; Bath University; Pets at Home; Weavers plc.

Spec.

Preparatory work and application in accordance with manufacturer’s instructions.

Vapour permeability to ASTM E96:90

Product:   Pageseal DPM

Thickness: 0.5 mm (approx.)

2 coat surface DPM to be supplied and laid on a sound shot blasted and vacuum cleaned in situ concrete slab. Product: Pageseal One Coat

Thickness: 0.3 mm (approx.)

One coat moisture suppressant, to be supplied and laid on a sound shot blasted and vacuum cleaned in situ concrete slab (not exceeding 85% Relative Humidity).

Note: Pageseal DPM is not designed to resist hydrostatic water pressure. In such circumstances external tanking or pressure relief, by e.g. directed drainage, must be provided to the structure.

Installation Service: The installation should be carried out by a Page approved contractor. Obtain details of our approved contractors by contacting our customer service team or inquiring via our website www.pageindustrialcoatings.co.uk

Technical

The figures that follow are typical properties achieved in laboratory tests at 20 oC and at 50% Relative Humidity.
5 gms / m2 / 24 hrs
Water Permeability Nil – Karsten test (impermeable)
Compressive Strength 50 N/mm2 (BS6319)
Flexural Strength 20 N/mm2 (BS6319)
Tensile Strength 15 N/mm2 (BS6319)
Bond Strength Greater than cohesive strength of 25 N/mm2 concrete. >1.5 MPa.

Speed of Cure:

Light traffic: 10°c: 48 hrs; 20°c: 16 hrs; 30°c: 12 hrs

Full traffic: 10°c: 72 hrs; 20°c: 48 hrs; 30°c: 40 hrs

Full chemical cure: 10°c: 12 days; 20°c: 7 days; 30°c:  7 days

Overlaying

Resin floor finishes can be laid directly onto Pageseal DPM. If there is no sand blind applied to the Pageseal DPM, then the resin floor finish should be applied within 24 hours of the application of the Pageseal DPM.

For direct bonding to Pageseal DPM, the adhesive manufacturer should be consulted to determine if a sanded or unsanded finish is required.

Life Expectancy

Pageseal DPM is in practice a permanent membrane to protect final finishes from moisture related damage for the life of the floor, subject to there being no structural movement nor failure of the concrete slab, no severe thermal cycling nor exposure to temperatures above 50oC.

Environment

The finished system is assessed as non-hazardous to health and the environment. The controlled moisture vapour permeability provided by Pageseal DPM enhances the service life of the flooring system, reducing the need for repairs and maintenance. Environmental and health considerations are controlled during manufacture and application of the products by Page staff and fully trained and experienced contractors.

Focus on the Floorzone

Page are market leaders in specialist industrial and commercial flooring. Systems available include: underfloor heating systems, floor screeds, surface damp proof membranes, decorative floor finishes, seamless terrazzo, car park deck waterproofing, corrosion protection systems… to name just a few. Our objective is to satisfy your Floorzone needs.

Further Information

To ensure you are specifying a fit for purpose flooring for your project please consult our Technical Advisors on the number below or visit our website to register your interest in specifying one of the most durable floors on the market.
